Aircut 140IN
Explore our Plasma solutions, providing efficient cutting, high-quality performance, and reliability for diverse industrial applications and demanding tasks
Explore our Plasma solutions, providing efficient cutting, high-quality performance, and reliability for diverse industrial applications and demanding tasks
The Aircut 140IN by Bweld is an IGBT-based inverter arc welding machine designed for efficiency and reliability. It features automatic protection against overcurrent and overvoltage, ensuring safe operations. Equipped with an air filter and regulator, it can automatically rebalance voltage variations within a specific range. The 2T/4T modes reduce effort during use, delivering a smooth cutting surface with high cutting efficiency. Its advanced technology ensures stable performance for demanding applications.
Description
Manual cutting torch
Earthing cable with clamp
Specification
| Technical Specification | Aircut 140IN |
|---|---|
| Supply voltage (V) | 3 phase 415 V |
| Rated Input Current(A) | 29A |
| Rated Input Power(KVA) | 29KVA |
| Current Range(A) | 60-120A |
| No Load Voltage(V) | 280V |
| Frequency(Hz) | 50 Hz |
| Power Factor | O.93 |
| Duty Cycle(%) | 60% |
| Efficiency | 85% |
| Compressor | Inbuilt |
| Insulation Class | H |
| Cooling Mode | Air Cooled |
| Protection Class | IP21S |
| Production cutting Thickness(mm) | 14/20mm |
| Cutting Thickness(mm) | 20/30mm |
| Rough Cutting Thickness(mm) | 25/32mm |
| Weight(Kg)(approximate) | 28KG |
