MIG 250
Discover our GMAW/MIG solutions offering fast efficient high-quality welding for various materials ensuring strong durable results
Discover our GMAW/MIG solutions offering fast efficient high-quality welding for various materials ensuring strong durable results
The Bweld MIG 250 is a versatile and efficient welding solution designed for medium-duty applications. It offers stable welding performance with advanced inverter technology, ensuring consistent arc quality and minimal spatter. Featuring easy arc ignition, high deposition efficiency, and smooth wire feeding, it delivers professional-grade results. Compact and portable, the MIG 250 includes adjustable welding parameters and energy-saving functionality, making it ideal for precise and cost-effective welding tasks.
Description
Input Cable
Mig Torch, Earthing Cable and Clamp
Heater, CO2 Regulator, Flow meter
Specification
| Technical Specification | MIG 250 |
|---|---|
| Supply voltage (V) | 3 phase 415V |
| Rated Input Current(A) | 16A |
| Rated Input Power(KVA) | 12KVA |
| Welding Current Range(A) | 30-250A |
| No Load Voltage(V) | 65V |
| Frequency(Hz) | 50 Hz |
| Power Factor | O.93 |
| Duty Cycle(%) | 60% |
| Wire Diameter( mm ) | 0.8/1.0 |
| Wire feeder | Separate |
| Feeding Speed(m/min) | 1.5-15m/mm |
| Efficiency | 85% |
| Insulation Class | F |
| Cooling Mode | Air Cooled |
| Protection Class | IP21S |
| Weight(Kg)(approximate) | 20KG |
